Pressure gauge – inline type
Part # 732
This pressure gauge comes ready to attach to all systems with 1/4" tubing
It is helpful in monitoring the
house water pressure
operating pressure of the RO system
determining when to replace the bottom three sediment filter and carbon filters.
It’s also helpful during installation and trouble shooting.
Diameter of the gauge: 1.5”
connector of the gauge: 1/8" MPT
Range: 0 to 300 psi
It comes with
Best place to connect the pressure gauge:
It's best to connect the pressure gauge at the input side of the 4th stage RO membrane filter.
It can be attached to a garden hose adapter (part no. 745) or a faucet adapter (part no. 741) for easy checking of house water pressure.
